  • TL-SCB-68 HSDIO Terminal Block

  • TL-SCB-68 HSDIO Terminal Block

    TL-SCB-68 HSDIO Quick Reference Label Series and HSDIO Devices DIO Connector is a shielded I/O connector terminal block。


    • ￥0.00
      ￥0.00
    • Quantity：
    • Request a quote
Product Description

TL-SCB-68 HSDIO Quick Reference Label Series and HSDIO Devices DIO Connector is a shielded I/O connector terminal block。


TL-SCB-68 HSDIO Quick Reference Label Series and HSDIO Devices DIO Connector is a shielded I/O connector terminal block with 72 screw terminals,designed for connecting signals to a 68 PIN VHDCI connector.





General

Operating Current1 A
Operating Voltage250 V
Single-ended impedance control50 Ω
Propagation delay:1.1 ns
Skew between channels32 PS



Connector

ConnectorVHDCI68 female
Conductor MaterialCopper alloy
Contact Resistance≤35 mΩ
Side ScrewsM2.0





Terminal block

Connection TypeScrew clamp
Conductor Cross-Sectional Area0.2–0.25 mm²
Screw Torque0.5–0.6 N·m
Contact MaterialTin-plated copper
SMB Mounting Holes38 units, unfilled
Through-Hole Pads0.6 to 1.5 mm


Enclosure

Main Body MaterialAluminum alloy
Dimensions (including legs)14.7 x 14.7 x 3.0 cm
Weight650 g
